ASTM B704 Incoloy 825 Welded Pipes Supplier and Exporter | UNS N08825, NCF 825 & DIN 2.4858 | Leoscor Alloy Pipes
Incoloy 825 Welded Pipes are nickel-iron-chromium alloy pipes designed for applications requiring excellent corrosion resistance, mechanical strength, and stable performance in aggressive environments. The addition of molybdenum, copper, and titanium improves resistance against pitting, crevice corrosion, and intergranular corrosion.
Leoscor Alloy Pipes is a trusted manufacturer, stockist, supplier, and exporter of ASTM B704 Incoloy 825 Welded Pipes, offering high-quality welded pipe solutions manufactured according to ASTM/ASME standards and customized customer requirements.
Incoloy 825 Welded Pipes are nickel-based alloy pipes containing nickel, chromium, iron, molybdenum, copper, and titanium. These alloying elements provide excellent resistance against chemical corrosion, acidic environments, and chloride-containing conditions.
ASTM B704 Incoloy 825 Welded Pipes are manufactured using welded fabrication processes and are available in different sizes, wall thicknesses, lengths, and specifications.
These pipes are widely used in applications involving corrosive fluids, chemical processing, and high-performance industrial systems.
The grade is internationally identified through different material designations including UNS N08825 Welded Pipes, NCF 825 Welded Pipes, and DIN 2.4858 Welded Pipes.
Leoscor Alloy Pipes supplies premium-quality Nickel Alloy Pipes including ASTM B704 Incoloy 825 Welded Pipes with customized dimensions, inspection documents, and technical support. Contact us today to discuss your requirements and get a competitive quotation.
Equivalent Names of Incoloy 825 Welded Pipes
| Equivalent Name | Standard / Country | Explanation |
|---|---|---|
| UNS N08825 Welded Pipes | USA (Unified Numbering System) | Material designation used for Incoloy 825 Welded Pipes. |
| NCF 825 Welded Pipes | Japan (JIS Comparable Standard) | Comparable Japanese designation for Incoloy 825 Welded Pipes. |
| DIN 2.4858 Welded Pipes | Germany / Europe (DIN Standard) | Material number used for Incoloy 825 Welded Pipes. |
Key Features of Incoloy 825 Welded Pipes
- Excellent resistance to general corrosion
- High resistance to pitting and crevice corrosion
- Good resistance against acidic environments
- Excellent weldability
- Good mechanical strength
- Stable performance in chemical processing conditions
- Suitable for high-temperature and corrosive applications
ASTM B704 Incoloy 825 Welded Pipe Specifications
Standard specifications for ASTM B704 Incoloy 825 Pipe. If any specification is not mentioned here, you can contact us. We also manufacture and export custom specifications as per client’s requirements.
| Specifications | Details |
|---|---|
| Specifications | ASTM B704 / ASME SB704 |
| Dimensions | ASTM, ASME and API |
| Size | 1/8″ NB to 30″ NB |
| Specialized In | Large Diameter Size |
| Type | ERW / Welded / Fabricated / LSAW Pipes |
| Form | Round, Square, Rectangular, Hydraulic Pipes |
| Schedule | SCH 20, SCH 30, SCH 40, STD, SCH 80, XS, SCH 60, SCH 80, SCH 120, SCH 140, SCH 160, XXS |
Incoloy 825 ASTM B704 Welded Pipe - Industries & Applications
Our pipes and tubes are used in a wide range of applications and various industries. Below are a few of them:
- Gas Processing Industries
- Petrochemical Industries
- Power Generation Industries
- Food Processing Industries
- Chemical Industries
- Oil & Gas Industries
- Fertilizers Industries
- Sugar Industries
Types of ASTM B704 Incoloy 825 Welded Pipe
| Incoloy Alloy 825 ASTM B704 Welded Pipe | Incoloy ASTM B704 Welded Pipe |
| Incoloy 825 B704 Welded Pipe | Incoloy Alloy 825 ASTM B704 ERW Pipe |
| Incoloy ASTM B704 ERW Pipe | Incoloy 825 B704 ERW Pipe |
| Incoloy Alloy 825 ASTM B704 Fabricated Pipe | Incoloy ASTM B704 Fabricated Pipe |
| Incoloy 825 B704 Fabricated Pipe | Incoloy Alloy 825 ASTM B704 LSAW Pipe |
| Incoloy ASTM B704 LSAW Pipe | Incoloy 825 B704 LSAW Pipe |
| Incoloy 825 B704 Pipe | Incoloy Alloy NCF 825 Pipes |
| Incoloy Alloy UNS N08825 Pipes | Incoloy DIN 2.4858 Pipe |
Incoloy 825 ASTM B704 Welded Pipe Chemical Composition
| Grade | ASTM B704 Incoloy 825 | |
|---|---|---|
| min | max | |
| C | – | 0.05 |
| Mn | – | 1.0 |
| Si | – | 0.5 |
| Al | – | 0.2 |
| S | – | 0.015 |
| Cr | 19.5 | 23.5 |
| Ti | 0.6 | 1.2 |
| Mb | 2.5 | 3.5 |
| Ni | 38.0 | 46.0 |
| Cu | 1.5 | 3.0 |
| Fe | 22.0 | – |
ASTM B704 Incoloy 825 Welded Pipe Mechanical Properties
| Grade | ASTM B704 Incoloy 825 | |
|---|---|---|
| Tensile Strength (MPa) min | Psi – 80000 , MPa – 550 | |
| Yield Strength 0.2% Proof (MPa) min | Psi – 32000 , MPa – 220 | |
| Elongation (% in 50mm) min | 30% | |
Incoloy 825 Welded Pipe Physical Properties
| Grade | ASTM B704 Incoloy 825 | |
|---|---|---|
| Density | 8.14 g/cm3 | |
| Melting Point | 1400 °C (2550 °F) | |
Incoloy ASTM B704 825 Welded Pipe Equivalent Grades
| Grade | ASTM B704 Incoloy 825 | |
| UNS No | N08825 | |
| Old British | BS | NA 16 |
| En | NiCr21Mo | |
| Euronorm | No | 2.4858 |
| AFNOR | NFE30C20DUM | |
| Japanese JIS | NCF 825 | |
| GOST | ЭП703 | |
Incoloy B704 Welded Pipe Price List
Leoscor Alloys is one of the most competitive suppliers of pipes and tubes from India. Our prices for ASTM B704 Incoloy 825 Pipe are very competitive.
Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. Leoscor Alloys maintains a stock of all standard items and can export them at best price for Nickel Alloy ASTM B704 Incoloy 825 Seamless and Welded Pipes.
ASTM B704 Incoloy 825 Welded Pipe Stock Availability
We maintain huge inventories of all standard sizes and grades. Please send us your complete requirement and we will send you the availability with the best quote for ASTM B704 Incoloy 825 Pipe.
