316L Stainless Steel Tubes Supplier and Exporter | UNS S31603, SUS 316L & DIN 1.4404 | Leoscor Alloy Pipes
316L Stainless Steel Tubes are low-carbon austenitic stainless steel tubes designed for applications requiring excellent corrosion resistance, superior weldability, and reliable performance in aggressive environments. The low carbon content helps reduce carbide precipitation during welding, making these tubes suitable for welded structures and critical industrial applications.
Leoscor Alloy Pipes is a trusted manufacturer, stockist, supplier, and exporter of SS 316L Tubes, offering high-quality seamless and welded tube solutions for industries such as marine, chemical processing, pharmaceutical, food processing, and heat exchanger applications.
316L Stainless Steel Tubes are the low-carbon version of 316 stainless steel tubes, containing chromium, nickel, and molybdenum as major alloying elements. The addition of molybdenum improves resistance against pitting and crevice corrosion, especially in chloride-rich and marine environments.
The reduced carbon content improves welding performance and helps maintain corrosion resistance after fabrication. Due to these properties, SUS 316L Tubes are widely used in applications where long-term durability, corrosion resistance, and hygienic performance are required.
316L Stainless Steel Tubes are available in seamless, welded, ERW, and EFW forms. They can be supplied in various shapes including round, square, rectangular, oval, and hollow sections. Different finishes such as cold drawn, hot rolled, cold rolled, annealed, pickled, and electropolished are available according to application requirements.
Equivalent Names of 316L Stainless Steel Tubes
| Equivalent Name | Standard / Country | Explanation |
|---|---|---|
| UNS S31603 Tubes | USA (Unified Numbering System) | Material designation used for low-carbon 316L stainless steel tubes. |
| SUS 316L Tubes | Japan (JIS Standard) | Japanese designation used for 316L stainless steel tubes. |
| DIN 1.4404 Tubes | Germany / Europe (DIN EN Standard) | European material number used for 316L stainless steel tubes. |
| X2CrNiMo17-12-2 Tubes | Europe (EN Chemical Designation) | Chemical composition designation representing 316L stainless steel grade. |
Key Features of 316L Stainless Steel Tubes
- Excellent Corrosion Resistance: Provides superior protection against pitting and crevice corrosion.
- Low Carbon Content: Reduces carbide precipitation during welding.
- Excellent Weldability: Suitable for fabricated and welded tube applications.
- Marine Grade Performance: Performs well in saltwater and chloride environments.
- High Durability: Provides long service life under demanding conditions.
- Good Mechanical Strength: Suitable for pressure and structural applications.
- Hygienic Surface Options: Available with electropolished finishes for clean applications.
- Multiple Forms Available: Supplied in seamless, welded, ERW, and EFW constructions.
SS 316L Tubes Specifications
Standard specifications for SS 316L Tubes. If any specification is not mentioned here, you can contact us. We also manufacture and export custom specifications as per client’s requirements.
| Specifications | Details |
|---|---|
| Specifications | ASTM A213 / ASME SA213 / ASTM A249 / ASTM A269 |
| Dimensions | ASTM, ASME and API |
| SS 316L Tubes | 1/8″ NB to 30″ NB |
| Thickness | 0.35 mm to 6.35 mm OD, with thickness ranging from 0.1 mm to 1.2 mm. |
| Schedule | SCH 20, SCH 30, SCH 40, STD, SCH 80, XS, SCH 60, SCH 80, SCH 120, SCH 140, SCH 160, XXS |
| Type | Seamless / ERW / Welded / Fabricated / LSAW Tubes |
| Form | Round, Square, Rectangular, Hydraulic Tubes |
| Length | Single Random, Double Random & Cut Length |
| End | Plain End, Beveled End, Threaded |
316L Stainless Steel Welded Tubes - Industries & Applications
Our pipes and tubes are used in a wide range of applications and various industries. Below are a few of them:
- Gas Processing Industries
- Petrochemical Industries
- Power Generation Industries
- Food Processing Industries
- Chemical Industries
- Oil & Gas Industries
- Fertilizers Industries
- Sugar Industries
Types of Stainless Steel 316L Tubes
| Stainless Steel 316L Welded Tubes | 316L SS Welded Tubes |
| 316L Stainless Steel Seamless Tubes | SS 316L Seamless Tubes |
| SS 316L ERW Tubes | 316L Stainless Steel ERW Tubes |
| 316L SS Fabricated Tubes | Stainless Steel 316L Fabricated Tubes |
| SS 316L LSAW Tubes | 316L Stainless Steel LSAW Tubes |
| 316L Stainless Steel Polished Tubes | SS 316L Polished Tubes |
| Stainless Steel 316L Cold Drawn Tubes | 316L SS Cold Drawn Tubes |
| 316L SS Hot Rolled Tubes | Stainless Steel 316L Hot Rolled Tubes |
| SS 316L Cold Rolled Tubes | 316L Stainless Steel Cold Rolled Tubes |
| Stainless Steel 316L Square Tubes | 316L SS Round Tubes |
| 316L SS Hexagonal Tubes | Stainless Steel 316L Tubes |
316L SS Seamless Tubes Chemical Composition
| Grade | 316L | |
|---|---|---|
| min | max | |
| C | – | 0.035 |
| Mn | – | 2.0 |
| Si | – | 0.75 |
| P | – | 0.045 |
| S | – | 0.030 |
| Cr | 16.0 | 18.0 |
| Mo | 2.0 | 3.0 |
| Ni | 10.0 | 14.0 |
| N | – | – |
ASTM A213 SS 316L Welded Tubes Mechanical Properties
| Grade | 316L | |
|---|---|---|
| Tensile Strength (MPa) min | 485 | |
| Yield Strength 0.2% Proof (MPa) min | 170 | |
| Elongation (% in 50mm) min | 40 | |
| Hardness | Rockwell B (HR B) max | 95 |
| Rockwell B (HR B) max | 217 | |
Stainless Steel 316L Tubes Physical Properties
| Grade | 316L | |
|---|---|---|
| Density (kg/m3) | 8000 | |
| Elastic Modulus (GPa) | 193 | |
| Mean Coefficient of Thermal Expansion (m/m/0C) | 0-1000C | 15.9 |
| 0-3150C | 16.2 | |
| 0-5380C | 17.5 | |
| Thermal Conductivity (W/m.K) | at 1000C | 16.3 |
| at 5000C | 21.5 | |
| Specific Heat 0-1000C (J/kg.K) | 500 | |
| Electrical Resistivity (n.m) | 740 | |
SS 316L Tubes Equivalent Grades
| Grade | 316L | |
| UNS No | S31603 | |
| Old British | BS | 316S11 / 316S13 |
| En | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 | |
| Euronorm | No | 1.4404 / 1.4435 |
| AFNOR | Z3CND17-11-02 / Z3CND18-04-03 | |
| Swedish SS | – | |
| Japanese JIS | SUS 316L | |
| GOST | 03Ch17N14M3 / 03Ch17N14M2 | |
Stainless Steel 316L Tubes Price List
Leoscor Alloys is one of the most competitive suppliers of pipes and tubes from India. Our prices for SS 316L Tubes are very competitive.
Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. Leoscor Alloys maintains a stock of all standard items and can export them at best price for 316L Stainless Steel Seamless and Welded Tubes.
ASTM A213 SS 316L Tubing Stock Availability
We maintain huge inventories of all standard sizes and grades. Please send us your complete requirement and we will send you the availability with the best quote for Stainless Steel 316L Tubes.
