ASTM B622 Hastelloy C22 Tube Supplier and Exporter | UNS N06022 & DIN 2.4602 | Leoscor Alloy Pipes
ASTM B622 Hastelloy C22 Tubes supplied by Leoscor Alloy Pipes are nickel-chromium-molybdenum alloy tubes designed for applications requiring excellent corrosion resistance, high strength, and reliable performance in aggressive chemical environments.
Hastelloy C22 Tubes contain nickel, chromium, molybdenum, and tungsten as major alloying elements. This balanced composition provides excellent resistance against pitting, crevice corrosion, stress corrosion cracking, and oxidizing as well as reducing environments.
Leoscor Alloy Pipes is a trusted manufacturer, stockist, supplier, and exporter of ASTM B622 Hastelloy C22 Tubes, available in different sizes, dimensions, shapes, and manufacturing forms including seamless, cold drawn, cold rolled, ERW, EFW, and customized options.
ASTM B622 Hastelloy C22 Tubes are nickel-based alloy tubes developed for highly corrosive applications where superior resistance against chemical attack is required.
These tubes provide excellent protection against chloride environments, oxidizing media, acids, and chemical processing conditions. The alloy offers improved resistance to localized corrosion compared with many conventional stainless steel grades.
The grade is internationally identified through different designations including ASTM B622 Hastelloy C22 Tubes, UNS N06022 Tubes, and DIN 2.4602 Tubes.
Leoscor Alloy Pipes supplies premium-quality Nickel Alloy Tubes including ASTM B622 Hastelloy C22 Tubes in customized sizes, specifications, and finishes. Contact us today to discuss your requirements and get a competitive quotation.
ASTM B622 Hastelloy C22 Tube - Quick Section Links
ASTM B622 Hastelloy C22 Tube
Equivalent Names of ASTM B622 Hastelloy C22 Tubes
| Equivalent Name | Standard / Country | Explanation |
|---|---|---|
| ASTM B622 Hastelloy C22 Tubes | ASTM Standard | Specification designation for Hastelloy C22 Tubes. |
| UNS N06022 Tubes | USA (Unified Numbering System) | Material designation used for Hastelloy C22 Tubes. |
| DIN 2.4602 Tubes | Germany / Europe (DIN/EN Standard) | European material number for Hastelloy C22 Tubes. |
Key Features of Hastelloy C22 Tubes
- Excellent resistance to pitting and crevice corrosion
- Superior resistance to chloride environments
- High resistance to oxidizing and reducing acids
- Good weldability
- High mechanical strength
- Excellent chemical stability
- Long service life in aggressive environments
Standard Specifications of ASTM B622 Hastelloy C22 Tube
Standard specifications for ASTM B622 Hastelloy C22 Tube. If any specification is not mentioned here, you can contact us. We also manufacture and export custom specifications as per client’s requirements.
| Specifications | Details |
|---|---|
| Specifications | ASTM B622 / ASME SB622 |
| Dimensions | ASTM, ASME and API |
| Size | 1/8″ NB to 30″ NB |
| Specialized In | Large Diameter Size |
| Range | Seamless tubes 6 mm OD x 0.7 mm to 50.8 mm OD x 3 mm thickness |
| Type | Seamless / ERW / Fabricated / LSAW Tubes |
| Form | Round, Square, Rectangular, Hydraulic Tubes |
| Length | Single Random, Double Random & Cut Length |
| End | Plain End, Beveled End, Threaded End |
Hastelloy C22 Tube - Industries & Applications
Our pipes and tubes are used in a wide range of applications and various industries. Below are a few of them:
- Gas Processing Industries
- Petrochemical Industries
- Power Generation Industries
- Food Processing Industries
- Chemical Industries
- Oil & Gas Industries
- Fertilizers Industries
- Sugar Industries
Types of ASTM B622 Hastelloy C22 Tube
| Hastelloy Alloy C22 ASTM B622 LSAW Tube | Hastelloy ASTM B622 LSAW Tube |
| Hastelloy C22 B622 LSAW Tube | Hastelloy Alloy C22 ASTM B622 Seamless Tube |
| Hastelloy ASTM B622 Seamless Tube | Hastelloy C22 B622 Seamless Tube |
| Hastelloy Alloy C22 ASTM B622 ERW Tube | Hastelloy ASTM B622 ERW Tube |
| Hastelloy C22 B622 ERW Tube | Hastelloy Alloy C22 ASTM B622 Fabricated Tube |
| Hastelloy ASTM B622 Fabricated Tube | Hastelloy C22 ASTM B622 Fabricated Tube |
| Hastelloy C22 B622 Tube | Hastelloy Alloy NW 6022 Tubes |
| Hastelloy Alloy UNS N06022 Tubes | Hastelloy DIN 2.4602 Tube |
Hastelloy C22 ASTM B622 Tube Chemical Composition
| Grade | ASTM B622 Hastelloy C22 | |
|---|---|---|
| min | max | |
| C | – | 0.010 |
| Mn | – | 0.50 |
| Si | – | 0.08 |
| P | – | 0.02 |
| S | – | 0.02 |
| Mo | 12.5 | 14.5 |
| Ni | Balance | Balance |
| Cr | 20.0 | 22.5 |
| Fe | 2.0 | 6.0 |
| Co | – | 2.5 |
| V | – | 0.35 |
| W | 2.5 | 3.5 |
ASTM B622 Hastelloy C22 Tube Mechanical Properties
| Grade | ASTM B622 Hastelloy C22 | |
|---|---|---|
| Tensile Strength (MPa) min | Psi – 100000 , MPa – 690 | |
| Yield Strength 0.2% Proof (MPa) min | Psi – 45000 , MPa – 310 | |
| Elongation (% in 50mm) min | 45% | |
Hastelloy C22 Tube Physical Properties
| Grade | ASTM B622 Hastelloy C22 | |
|---|---|---|
| Density | 8.69 g/cm3 | |
| Melting Point | 1399 °C (2550 °F) | |
Hastelloy ASTM B622 C22 Tube Equivalent Grades
| Grade | ASTM B622 Hastelloy C22 | |
| UNS No | N06022 | |
| Old British | BS | – |
| En | NiCr21Mo14W | |
| Euronorm | No | 2.4602 |
| Name | – | |
| AFNOR | – | |
| Japanese JIS | NW 6022 | |
| GOST | – | |
Hastelloy C22 Tube Price List
Leoscor Alloys is one of the most competitive suppliers of pipes and tubes from India. Our prices for ASTM B622 Hastelloy C22 Tube are very competitive.
Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. Leoscor Alloys maintains a stock of all standard items and can export them at best price for ASTM B622 Hastelloy C22 Seamless Tubes.
ASTM B622 Hastelloy C22 Tube Stock Availability
We maintain huge inventories of all standard sizes and grades. Please send us your complete requirement and we will send you the availability with the best quote for ASTM B622 Hastelloy C22 Tube.
Why Buy ASTM B622 Hastelloy C22 Tube from Leoscor Alloys
Leoscor Alloys is a leading stockist, distributor, and supplier of ASTM B622 Hastelloy C22 from India. With more than three decades of experience, we understand the steel industry deeply. We have huge experience of supplying to all major industries across the world. Our team of dedicated experts with stringent quality policy ensures that we supply best-in-class products meeting and exceeding our client’s expectations. Below are a few quick points about why buying from Leoscor Alloys will give you an undue advantage:
- Huge inventory of all standard sizes and grades.
- Distributors of all reputed origins and manufacturers.
- Strict quality control policies and highly experienced team.
- Strong logistics & delivery channels.
- Modern Infrastructure with huge storage capacity.
- An ISO 9000:2015 Certified Company.
