304 Stainless Steel Pipes | UNS S30400, EN 1.4301 & SUS 304
Leoscor Alloy Pipes supplies 304 Stainless Steel Pipes for industrial piping, process lines, fabrication, water handling, food processing, chemical processing and general engineering applications.
Grade 304 is an austenitic stainless steel known for its corrosion resistance, weldability, forming characteristics and suitability for a wide range of industrial environments.
The same material grade may appear under different international designations in purchase orders, engineering drawings and material specifications. AISI 304, UNS S30400, EN 1.4301, X5CrNi18-10 and JIS SUS 304 are commonly cross-referenced designations for this stainless steel grade.
Leoscor Alloy Pipes supplies SS 304 pipes in seamless, ERW, welded, fabricated and LSAW types, with different sizes, schedules, lengths, forms and end preparations to meet project requirements.
304 Stainless Steel Pipe Grade Identification
| Standard or Designation System | Grade |
|---|---|
| AISI | 304 |
| UNS | S30400 |
| EN Material Number | 1.4301 |
| EN Material Name | X5CrNi18-10 |
| JIS | SUS 304 |
| Old British Standard | 304S31 |
| Swedish SS | 2332 |
304 stainless steel pipe is made from an austenitic chromium-nickel stainless steel. The grade contains 18.0 to 20.0 percent chromium and 8.0 to 10.5 percent nickel according to the composition values listed below.
This combination gives the material useful corrosion resistance along with good forming and welding characteristics.
SS 304 pipes are commonly selected where carbon steel would require greater corrosion protection and where the process does not require the higher chloride resistance associated with grades such as 316.
For engineering selection, the fluid, operating temperature, pressure, chloride level, fabrication method and applicable piping code should always be considered before the final material is approved.
ASTM A312 TP304 Stainless Steel Pipe
ASTM A312 is one of the important specifications associated with 304 stainless steel pipe.
For projects specifying ASTM A312 TP304, the designation identifies Grade 304 within the ASTM pipe specification.
Leoscor Alloy Pipes supplies 304 stainless steel pipes against requirements that include ASTM A312 / ASME SA312 and ASTM A358 / ASME SA358 as listed in the current product range.
A purchase order should not state only “SS 304.” It is better to include the required product standard, size, schedule or wall thickness, manufacturing type, length, end preparation and any inspection or documentation requirements.
SS 304 Pipe Specifications
| Specification | Available Details |
|---|---|
| Specifications | ASTM A312 / ASME SA312, ASTM A358 / ASME SA358 |
| Dimensions | ASTM, ASME and API |
| SS 304 Pipes | 1/2 inch NB to 16 inch NB |
| ERW 304 Pipes | 1/2 inch NB to 24 inch NB |
| EFW 304 Pipes | 6 inch NB to 100 inch NB |
| Size | 1/8 inch NB to 30 inch NB |
| Schedule | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Type | Seamless, ERW, Welded, Fabricated, LSAW Pipes |
| Form | Round Pipes, Custom Pipes, Square Pipes, Rectangular Pipes, U Shape, Hydraulic Pipes |
| Length | Single Random, Double Random and Cut Length |
| End | Plain End, Beveled End, Threaded |
For an accurate quotation, the enquiry should identify the exact size and schedule rather than specifying only the nominal diameter.
304 Stainless Steel Pipe Chemical Composition
The chemical composition currently specified for Leoscor Alloy Pipes Grade 304 material is shown below.
| Element | Minimum % | Maximum % |
|---|---|---|
| Carbon, C | – | 0.08 |
| Manganese, Mn | – | 2.0 |
| Silicon, Si | – | 0.75 |
| Phosphorus, P | – | 0.045 |
| Sulfur, S | – | 0.030 |
| Chromium, Cr | 18.0 | 20.0 |
| Molybdenum, Mo | – | – |
| Nickel, Ni | 8.0 | 10.5 |
| Nitrogen, N | – | 0.10 |
Chromium and nickel are important alloying elements in Grade 304. Chromium supports the passive surface layer associated with stainless steel corrosion resistance, while nickel helps maintain the austenitic structure and contributes to forming and mechanical characteristics.
The final chemistry of supplied material should be confirmed from the applicable material certificate against the specification stated in the purchase order.
304 Stainless Steel Pipe Mechanical Properties
| Property | Grade 304 |
|---|---|
| Tensile Strength, minimum | 515 MPa |
| Yield Strength, 0.2% Proof, minimum | 205 MPa |
| Elongation in 50 mm, minimum | 40% |
| Rockwell B Hardness, maximum | 92 HRB |
| Brinell Hardness, maximum | 201 HB |
Mechanical properties are important when engineers review the material for pressure piping, fabrication and structural service.
The actual acceptance criteria should follow the material specification and project code stated in the purchase documentation.
304 Stainless Steel Pipe Physical Properties
| Property | Grade 304 |
|---|---|
| Density | 8000 kg/m³ |
| Elastic Modulus | 193 GPa |
| Mean Coefficient of Thermal Expansion, 0 to 100°C | 17.2 |
| Mean Coefficient of Thermal Expansion, 0 to 315°C | 17.8 |
| Mean Coefficient of Thermal Expansion, 0 to 538°C | 18.4 |
| Thermal Conductivity at 100°C | 16.2 W/m.K |
| Thermal Conductivity at 500°C | 21.5 W/m.K |
| Specific Heat, 0 to 100°C | 500 J/kg.K |
| Electrical Resistivity | 720 n.m |
These properties can be useful during engineering calculations involving thermal expansion, heat transfer, equipment design and piping support.
The design engineer should use the values required by the applicable design code for final calculations.
UNS S30400 / EN 1.4301 / SUS 304 Stainless Steel Pipe
UNS S30400, EN 1.4301, X5CrNi18-10 and SUS 304 are commonly used designations for Grade 304 stainless steel.
For procurement, specify the complete grade and product standard, such as:
ASTM A312 TP304 / ASME SA312, UNS S30400
These pipes are used in food processing, chemical processing, water handling, petrochemical service and general industrial piping.
Leoscor Alloy Pipes supplies Grade 304 pipes in seamless, ERW, welded, fabricated and other available forms.
Product Details
| Parameter | Details |
|---|---|
| Grade | Stainless Steel 304 |
| UNS | S30400 |
| EN Number | 1.4301 |
| EN Name | X5CrNi18-10 |
| JIS | SUS 304 |
| Specifications | ASTM A312 / ASME SA312, ASTM A358 / ASME SA358 |
| Size Range | 1/8 inch NB to 30 inch NB |
| Types | Seamless, ERW, Welded, Fabricated, LSAW |
| Lengths | Single Random, Double Random, Cut Length |
| Ends | Plain, Beveled, Threaded |
Are 304, S30400, 1.4301 and SUS 304 the Same?
They are commonly cross-referenced designations for Grade 304 stainless steel. However, product standards, dimensions, tolerances, manufacturing requirements and certification must be confirmed separately.
| System | Designation |
|---|---|
| AISI | 304 |
| UNS | S30400 |
| EN | 1.4301 |
| EN Name | X5CrNi18-10 |
| JIS | SUS 304 |
For example, a buyer requiring ASTM A312 TP304 should include ASTM A312 in the purchase enquiry rather than specifying only “304 pipe”.
Stainless Steel 304 Pipes Price List
Leoscor Alloys Pipes is one of the most competitive suppliers of pipes and tubes from India. Our prices for SS 304 Pipes are very competitive.
Please click on the request a quote button or click here to request the updated price list and ready stock information along with your requirement. Leoscor Alloys maintains a stock of all standard items and can export them at best price for 304 Stainless Steel Seamless and Welded Pipes.
304 SS Pipes - Industries & Applications
Our pipes and tubes are used in a wide range of applications and various industries. Below are a few of them:
- Gas Processing Industries
- Petrochemical Industries
- Power Generation Industries
- Food Processing Industries
- Chemical Industries
- Oil & Gas Industries
- Fertilizers Industries
- Sugar Industries
Stainless Steel 304 Pipes Stock Availability
We maintain huge inventories of all standard sizes and grades. Please send us your complete requirement and we will send you the availability with best quote for Stainless Steel 304 Pipes.
Why Buy 304 Stainless Steel Pipes from Leoscor Alloys
Leoscor Alloys Pipes is a leading stockist, distributor and supplier of 304 Stainless Steel Pipes from India. With more than three decades of experience, we understand the steel industry deeply. We have huge experience of supplying to all major industries across the world. Our team of dedicated experts with stringent quality policy ensures that we supply best-in-class products meeting and exceeding our client’s expectations. Below are a few quick points about why buying from Leoscor Alloys Pipes will give you an undue advantage:
- Huge inventory of all standard sizes and grades.
- Distributors of all reputed origins and manufacturers.
- Strict quality control policies and highly experienced team.
- Strong logistics & delivery channels.
- Modern Infrastructure with huge storage capacity.
- An ISO 9000:2015 Certified Company.
